CANSSI Prairies — Epi Forecasting Workshop 2025

Introduction to Panel Data in Epidemiology

Lecture 1

Daniel J. McDonald

Outline

About
Workshop Overview and System Setup
Panel Data
Versioned Data
Epidata Repository and API
{epidatr} and Other Data
Versioning in {epidatr}

1 About

Daniel J. McDonald

PhD in Statistics from Carnegie Mellon University
Risk Bounds for Time series, esp. macroeconomic forecasting
Subsequent research and teaching on machine learning (model selection, optimization, regularization, nonparametrics)
Began working on epidemiology in mid-2020 with Delphi Research Group
Focus is largely on forecasting and nowcasting epidemic aggregates
Funding from US CDC (ongoing?), CSTE, NSERC, CANSSI

About Delphi

Founded in 2012 at Carnegie Mellon University, now expanded to UC Berkeley, and University of British Columbia.
Currently 5 faculty, ~10 PhD students, ~15 staff (mostly software engineers).
Easy to join us from anywhere (lots of volunteers during Covid-19 pandemic).
We are:
- CDC Center of Excellence for Influenza and Covid-19 Forecasting (2019-24).
- CDC Innovation Center for Outbreak Analytics and Disease Modeling (2024-29).

Our mission: To develop the theory and practice of epidemic detection, tracking and forecasting, and their use in decision making, both public and private.

What does Delphi do?

Procure real-time, aggregated data streams informative of infectious diseases and syndromes, in collaboration with partners in industry and government.
Extract signals and make them widely available via the Epidata platform & API.
Develop and deploy algorithms for epidemic detection, tracking, forecasting.
Develop and maintain statistical software packages for these tasks.
Make it all production-grade, maximally-accessible, and open-source (to serve CDC, state and local public health agencies, epi-forecasting researchers, data journalists, the public)

What we provide

Acknowledgements

Most of this material was developed for the InsightNet Tooling Workshop in December 2024.

Thanks to major contributors: Ryan J. Tibshirani; Rachel Lobay; Alice Clima; Logan Brooks; Delphi Tooling and Forecasting Team; Elvis Cai, Olivia Liu, Paul Gustafson

Funding: Center for Forecasting and Outbreak Analytics; Council of State and Territorial Epidemiologists; NSERC; CANSSI

2 Workshop Overview and System Setup

What we will cover

Characteristics of panel data in epidemiology
Tools for processing and plotting panel data
Statistical background on nowcasting and forecasting
Tools for building nowcasting and forecasting models
Plenty of examples throughout of real case studies

Goals part I

Present a statistical way of thinking about now/forecasting

Basic mindsets

data versioning and structure

the importance of empirical validation using techniques like time series cross-validation are ubiquitous

Certain basic modeling considerations

starting simple and building up complexity

taming variance through regularization,

addressing nonstationarity with trailing training windows

Goals part II

Present software whichs aid processing, tracking, nowcasting, and forecasting with panel data
These tools are still in development and we welcome your feedback
We have tried hard to get the framework right; but many individual pieces themselves could still be improved
If these aren’t working for you, then we want to hear from you!
We welcome collaboration, and everything we do is open source

A disclaimer

My background is primarily in statistics and computer science
This obviously influences my way of thinking and my approach to nowcasting and forecasting
I don’t have nearly as much experience with traditional epi models, but I do have opinions about the pros/cons.
Ask me at any point if you have a question about why I’m doing things a certain way

This workshop is supposed to be useful for YOU. Ask questions if you have them, don’t be shy
We may not (likely won’t?) cover everything. Hopefully the materials will be a resource for you beyond this workshop

System setup

install.packages("remotes")
install.packages("tidyverse")
install.packages("tidymodels")
install.packages("glmnet")
remotes::install_github("cmu-delphi/epidatr")
remotes::install_github("cmu-delphi/epidatasets")
remotes::install_github("cmu-delphi/epiprocess@dev")
remotes::install_github("cmu-delphi/epipredict@dev")
remotes::install_github("dajmcdon/rtestim")

Let’s take a few moments here.
You may also navigate to the GitHub repo and Clone/Fork the entire thing.

3 Panel Data

Panel data

Panel data is cross-sectional measurements of subjects over time.
With aggregated data, the subjects are geographic units (e.g. provinces, states).
Time index + one or more locations/keys.

# A tibble: 549 × 3
   time_value geo_value percent_cli
   <date>     <chr>           <dbl>
 1 2020-06-01 ca               2.75
 2 2020-06-02 ca               2.57
 3 2020-06-03 ca               2.48
 4 2020-06-04 ca               2.41
 5 2020-06-05 ca               2.57
 6 2020-06-06 ca               2.63
 7 2020-06-07 ca               2.73
 8 2020-06-08 ca               3.04
 9 2020-06-09 ca               2.97
10 2020-06-10 ca               2.99
# ℹ 539 more rows

The % of outpatient doctor visits that are COVID-related in CA, between June 2020 to Dec. 2021

Examples of panel data

JHU CSSE COVID-19 cases per 100k

Examples of panel data

Confirmed COVID-19 Hospital Admissions per 100k, 7day average

The \(x\)-axis is

Date of report

Not “date of event”

More disclaimers…

Most of this workshop will focus on panel data
Typical for the tasks my group has focused on
Typically analyze aggregate signals
Simultaneously across geographies
Contrasts with “single geo models”
Not working with “line list data”

4 Versioned Data

Intro to versioned data

→ Person comes to ER
→ Admitted
→ Has some tests
→ Tests come back
→ Entered into the system
→ …

Epidemic aggregates are subject to reporting delays and revisions

A “Hospital admission” may not attributable to a particular condition until a few days have passed

Additionally, various mistakes lead to revisions

Track both: when the event occurred and when it was reported

Intro to versioned data

Epidemic aggregates are subject to reporting delays and revisions

A “Hospital admission” may not attributable to a particular condition until a few days have passed

Additionally, various mistakes lead to revisions

Track both: when the event occurred and when it was reported

Versioned data

The event time is indicated by time_value (or reference_date)
Second time index indicates the data version (or reporting_date)

version = the time at which we saw a value associated to a time_value

# A tibble: 6 × 4
  time_value geo_value percent_cli version
  <date>     <chr>           <dbl> <date>
1 2020-06-01 ca               2.14 2020-06-06
2 2020-06-01 ca               2.14 2020-06-08
3 2020-06-01 ca               2.11 2020-06-09
4 2020-06-01 ca               2.13 2020-06-10
5 2020-06-01 ca               2.20 2020-06-11
6 2020-06-01 ca               2.23 2020-06-12

Versioned panel data

Estimated percentage of outpatient visits due to CLI across multiple versions.

Latency and revision in signals

Latency the delay between data collection and availability

Example

A signal based on insurance claims may take several days to appear as claims are processed

Revision data is updated or corrected after initial publication

Example

COVID-19 case reports are revised as reporting backlogs are cleared

Latency and revision in signals - Example

Recall the first example of panel & versioned data we’ve seen…

In June 2020, this signal is typically 4 days latent

# A tibble: 5 × 5
  time_value geo_value percent_cli version    latency
  <date>     <chr>           <dbl> <date>     <drtn>
1 2020-06-01 ca               2.14 2020-06-06 5 days
2 2020-06-02 ca               1.96 2020-06-06 4 days
3 2020-06-03 ca               1.77 2020-06-06 3 days
4 2020-06-04 ca               1.65 2020-06-08 4 days
5 2020-06-05 ca               1.60 2020-06-09 4 days

and subject to revision

# A tibble: 5 × 5
  time_value geo_value percent_cli version    latency
  <date>     <chr>           <dbl> <date>     <drtn>
1 2020-06-01 ca               2.14 2020-06-06  5 days
2 2020-06-01 ca               2.14 2020-06-08  7 days
3 2020-06-01 ca               2.11 2020-06-09  8 days
4 2020-06-01 ca               2.13 2020-06-10  9 days
5 2020-06-01 ca               2.20 2020-06-11 10 days

Revision triangle, Insurance Claims WA January 2022

7-day trailing average to smooth day-of-week effects

Revisions

Many data sources are subject to revisions:

Case and death counts are corrected or adjusted by authorities
Medical claims can take weeks to be submitted and processed
Surveys are not completed promptly

An accurate revision log is crucial for researchers building nowcasts and forecasts

Obvious but crucial

A forecast that is made today can only use data available “as of” today

Three types of revisions

Sources that don’t revise (provisional and final are the same)

Facebook Survey and Google symptoms

Predictable revisions

Claims data and public health reports aligned by test, hospitalization, or death date

Almost always revised upward as additional claims enter the pipeline

Revisions that are large and erratic to predict

COVID cases and deaths

These are aligned by report date

Types of revisions - Comparison between 2. and 3.

Revision behavior for two indicators in the HRR containing Charlotte, NC.
DV-CLI signal (left): regularly revised, but effects fade
JHU CSSE cases (right) remain “as first reported” until a major correction is made on Oct. 19

Reporting backlogs - Example

Bexar County, Texas, summer of 2020…

Large backlog of case reports results in a spike
Auxilliary signals show continued decline
Reports are not be trustworthy without context

5 Epidata Repository and API

What is the Epidata repository

Epidata: repository of aggregated epi-surveillance time series

Signals can be either public or restricted.

Currently contains over 5 billion records
During pandemic, handled millions of API queries per day
Many signals aren’t available elsewhere

Make epi-surveillance more nimble, complete, standardized, robust, and real-time

Features of Delphi Epidata

Built-in support for:
1. Data revisions (“backfill”), including reporting dates and changes
2. Geo levels w/ auto-aggregation (e.g. county, state, and nation) and specialized levels (e.g., DMA, sewer sheds)
3. Demographic breakdown
4. Representation for missingness and censoring
5. Population sizes and fine-grained population density
Customized smoothing and normalization
Access control
Code is Open Source.
Signals are as accessible (w/ API, SDK) as allowed by DUAs

Severity pyramid

https://delphi.cmu.edu/epiportal/

6 {epidatr}

Installing `{epidatr}`

(you already did this, but just for posterity…)

Install the CRAN version

# Install the CRAN version
install.packages("epidatr")

or the development version

# Install the development version from the GitHub dev branch
remotes::install_github("cmu-delphi/epidatr@dev")

The CRAN listing is here.

Python

In Python, install delphi-epidata from PyPI with

pip install delphi-epidata

delphi-epidata is soon to be replaced with epidatpy.

# Latest dev version
pip install -e "git+https://github.com/cmu-delphi/epidatpy.git#egg=epidatpy"

# PyPI version (not yet available)
pip install epidatpy

Using `{epidatr}` and `{epidatpy}`

library(epidatr)
hhs_flu_nc <- pub_covidcast(
  source = 'hhs',
  signals = 'confirmed_admissions_influenza_1d',
  geo_type = 'state',
  time_type = 'day',
  geo_values = 'nc',
  time_values = c(20240401, 20240405:20240414)
)
head(hhs_flu_nc, n = 3)

# A tibble: 3 × 15
  geo_value signal     source geo_type time_type time_value direction issue
  <chr>     <chr>      <chr>  <fct>    <fct>     <date>         <dbl> <date>
1 nc        confirmed… hhs    state    day       2024-04-01        NA 2024-04-22
2 nc        confirmed… hhs    state    day       2024-04-05        NA 2024-04-22
3 nc        confirmed… hhs    state    day       2024-04-06        NA 2024-04-22
# ℹ 7 more variables: lag <dbl>, missing_value <dbl>, missing_stderr <dbl>,
#   missing_sample_size <dbl>, value <dbl>, stderr <dbl>, sample_size <dbl>

Python equivalent:

res = Epidata.covidcast('hhs', 'confirmed_admissions_influenza_1d', 'day',
  'state', [20240401, Epidata.range(20240405, 20240414)], 'nc')

API keys

Anyone may access the Epidata API anonymously without providing any personal data!!
Anonymous API access is subject to some restrictions: public datasets only; 60 requests per hour; only two parameters may have multiple selections
API key grants privileged access; can be obtained by registering with us
Privileges of registration: no rate limit; no limit on multiple selections
We just want to know which signals people care about to ensure we’re providing benefit

Tip

The {epidatr} client automatically searches for the key in the DELPHI_EPIDATA_KEY environment variable.
We recommend storing it in your .Renviron file, which R reads by default.
More on setting your API key here.

Interactive tooling in R

avail_endpoints()

# A tibble: 28 × 2
   Endpoint                          Description
   <chr>                             <chr>
 1 pub_covid_hosp_facility()         COVID hospitalizations by facility
 2 pub_covid_hosp_facility_lookup()  Helper for finding COVID hospitalization f…
 3 pub_covid_hosp_state_timeseries() COVID hospitalizations by state
 4 pub_covidcast()                   Various COVID and flu signals via the COVI…
 5 pub_covidcast_meta()              Metadata for the COVIDcast endpoint
 6 pub_delphi()                      Delphi's ILINet outpatient doctor visits f…
 7 pub_dengue_nowcast()              Delphi's PAHO dengue nowcasts (North and S…
 8 pub_ecdc_ili()                    ECDC ILI incidence (Europe)
 9 pub_flusurv()                     CDC FluSurv flu hospitalizations
10 pub_fluview()                     CDC FluView ILINet outpatient doctor visits
11 pub_fluview_clinical()            CDC FluView flu tests from clinical labs
12 pub_fluview_meta()                Metadata for the FluView endpoint
13 pub_gft()                         Google Flu Trends flu search volume
14 pub_kcdc_ili()                    KCDC ILI incidence (Korea)
15 pub_meta()                        Metadata for the Delphi Epidata API
16 pub_nidss_dengue()                NIDSS dengue cases (Taiwan)
17 pub_nidss_flu()                   NIDSS flu doctor visits (Taiwan)
18 pub_nowcast()                     Delphi's ILI Nearby nowcasts
19 pub_paho_dengue()                 PAHO dengue data (North and South America)
20 pub_wiki()                        Wikipedia webpage counts by article
21 pvt_cdc()                         CDC total and by topic webpage visits
22 pvt_dengue_sensors()              PAHO dengue digital surveillance sensors (…
23 pvt_ght()                         Google Health Trends health topics search …
24 pvt_meta_norostat()               Metadata for the NoroSTAT endpoint
25 pvt_norostat()                    CDC NoroSTAT norovirus outbreaks
26 pvt_quidel()                      Quidel COVID-19 and influenza testing data
27 pvt_sensors()                     Influenza and dengue digital surveillance …
28 pvt_twitter()                     HealthTweets total and influenza-related t…

Fetching data - COVIDcast main endpoint

jhu_us_cases <- pub_covidcast(
  source = "jhu-csse",                        # this endpoint contains many different sources
  signals = "confirmed_7dav_incidence_prop",  # other signals: deaths, cumulative, etc.
  geo_type = "nation",                        # the geographic resolution (nation, state, hrr, msa, etc.)
  time_type = "day",                          # or week or year
  geo_values = "us",                          # optional
  time_values = epirange(20210101, 20210401), # optional
  ...                                         # additional arguments
)

# A tibble: 3 × 8
  geo_value signal             source geo_type time_value issue        lag value
  <chr>     <chr>              <chr>  <fct>    <date>     <date>     <dbl> <dbl>
1 us        confirmed_7dav_in… jhu-c… nation   2021-01-01 2023-03-10   798  61.9
2 us        confirmed_7dav_in… jhu-c… nation   2021-01-02 2023-03-10   797  64.2
3 us        confirmed_7dav_in… jhu-c… nation   2021-01-03 2023-03-10   796  67.1

value is the requested signal

There are some other columns in the usual output that I’ve hidden

Get everything for a `source + signal`

jhu_us_cases <- pub_covidcast(
  source = "jhu-csse",                  # this endpoint contains many different sources
  signals = "confirmed_incidence_num",  # raw cases during the entire pandemic reporting until ~ April 2024
  geo_type = "county",                  # the geographic resolution (nation, state, hrr, msa, etc.)
  time_type = "day",                    # lowest resolution
  geo_values = "*",                     # (default)
  time_values = "*",                    # (default)
  ...                                   # additional arguments
)

This query takes a few minutes to run, so I don’t recommend it.
But there is support for automatic caching,
and using "*" speeds things up relative to specifying many specific ranges.

The result has about 3.75M rows and occupies 400Mb.

7 Versioning in {epidatr}

Versioned data in `{epidatr}`

Two important, mutually exclusive parameters

`issues = c(mdy1, mdy2, ..., )`

fetches the data that the source made available on the requested dates
Database stores only the diffs, so that’s typically what you get
Even if the source republishes the entire history every time they make an update

`as_of = mdy`

fetches the all available data as it would have looked on mdy
Think of it as winding back the clock to the date mdy
API only accepts a single date here

Example `issues` query

I wanted to display a major reporting error.

versions <- as.Date(c("2021-02-15", "2021-02-20", "2021-02-25", "2021-03-01", "2023-01-01"))
pub_covidcast(
  "jhu-csse", "deaths_7dav_incidence_num",
  geo_type = "state",
  geo_values = "oh",
  time_type = "day",
  time_values = epirange(20210101,20210301),
  issues = versions
) |>
  select(geo_value, time_value, version = issue, deaths = value)

# A tibble: 4 × 4
  geo_value time_value version    deaths
  <chr>     <date>     <date>      <dbl>
1 oh        2021-02-14 2021-02-15  670.
2 oh        2021-02-19 2021-02-20   43.1
3 oh        2021-02-24 2021-02-25   42.3
4 oh        2021-02-28 2021-03-01   68.7

Not what I wanted.
Got only the diff on each issue.
I wanted to view the whole history on each of those dates.

Correct `as_of` query

res <- map(versions, # same set as before
           .f = \(v) {
             pub_covidcast(
               "jhu-csse", "deaths_7dav_incidence_num",
               geo_type = "state",
               geo_values = "oh",
               time_type = "day",
               time_values = epirange(20210101,20210301),
               as_of = v
             ) |>
               select(geo_value, time_value, deaths = value) |>
               mutate(version = v)
           }) |>
  list_rbind()
res |> head(7)

# A tibble: 7 × 4
  geo_value time_value deaths version
  <chr>     <date>      <dbl> <date>
1 oh        2021-01-01   72.3 2021-02-15
2 oh        2021-01-02   77.3 2021-02-15
3 oh        2021-01-03   81   2021-02-15
4 oh        2021-01-04   81.7 2021-02-15
5 oh        2021-01-05   75   2021-02-15
6 oh        2021-01-06   73.3 2021-02-15
7 oh        2021-01-07   71.4 2021-02-15

Got the data as it would have appeared for each of the 4 dates.
But as_of can only accept a scalar, not vector of dates.
Had to “loop” over them.
We’ll see a more efficient way to do this later this morning.

Now I can show you why I wanted that query

Versioning in nowcasting and forecasting

Revision patterns can be used to inform understanding of current situation
Often, predicting “today” is more about predicting the revisions than the process
Forecasting often requires adjustments for revision/reporting patterns
Backtesting requires using data that would have been available at the time, not current data
Only looking at the most recent data is a huge blunder

Wrapup and worksheet discussion

Versioned Data and Latency
1. as_of: One version; the specific date when the data was last updated
2. issues: Multiple versions; with different as_of dates
Epidata API: delivers up-to-date, granular epidemiological data + historical versions.
{epidatr}: Client package for R
Versioning and panel structure are key first steps for analysis

Introduction to Panel Data in Epidemiology

Daniel J. McDonald

Outline

1 About

Daniel J. McDonald

About Delphi

What does Delphi do?

What we provide

Acknowledgements

2 Workshop Overview and System Setup

What we will cover

Goals part I

Goals part II

A disclaimer

System setup

3 Panel Data

Panel data

Examples of panel data

Examples of panel data

More disclaimers…

4 Versioned Data

Intro to versioned data

Intro to versioned data

Versioned data

Versioned panel data

Latency and revision in signals

Latency and revision in signals - Example

Revision triangle, Insurance Claims WA January 2022

Revisions

Three types of revisions

Types of revisions - Comparison between 2. and 3.

Reporting backlogs - Example

5 Epidata Repository and API

What is the Epidata repository

Features of Delphi Epidata

Severity pyramid

6 {epidatr}

Installing {epidatr}

Python

Using {epidatr} and {epidatpy}

API keys

Interactive tooling in R

Fetching data - COVIDcast main endpoint

Get everything for a source + signal

7 Versioning in {epidatr}

Versioned data in {epidatr}

issues = c(mdy1, mdy2, ..., )

as_of = mdy

Example issues query

Correct as_of query

Now I can show you why I wanted that query

Versioning in nowcasting and forecasting

Wrapup and worksheet discussion

Installing `{epidatr}`

Using `{epidatr}` and `{epidatpy}`

Get everything for a `source + signal`

Versioned data in `{epidatr}`

`issues = c(mdy1, mdy2, ..., )`

`as_of = mdy`

Example `issues` query

Correct `as_of` query
